BNC to RJ45 Passive Video Balun for CCTV , CCTV Baluns Cat 5
1. Channel:1 CH
2. Impedance:
Coax, Male BNC: 75 ohms
RJ45/Terminal Block: 100 ohms
3. Medium:cat5 cable
4. Transmission Distance: 330m
5. UTP Port: "Press-Fit" terminal blocks
6. Compatible: NTSC, PAL, SECAM, CVI and AHD
7. Frequency Response: DC to 50MHz
8. Certification: CE, RoHS
Description:
The screwless video balun VB102PF is a passive transmission device that transmits video signal over unshielded twisted pair wires, point-to-point, for distances up to 1000 feet (330 m). It uses Category 5 UTP, are easy to install and cost effective, and do not require power.
The extremely compact size allows the video balun VB102PF to fit anywhere that a BNC can fit. It is ideal for mounting directly on virtually all high-density DVRs without any additional cabling. Its crosstalk and noise immunity ensure quality video signals.
Features:
Technical specifications:
|
Video Format |
NTSC, PAL, SECAM, CVI and AHD |
|
|
Frequency Response |
DC to 50MHz |
|
|
Attenuation |
0.5dB typ |
|
|
CMRR |
60 dB |
|
|
Impedance |
Coax, Male BNC |
75 ohms |
|
Terminal Block |
100 ohms |
|
|
Working environment |
Working Temperature |
-10℃ to +50℃ |
|
Storage Temperature |
-30℃ to +70℃ |
|
|
Humidity |
0 to 95% |
|
|
Wire Type |
UTP5 |
|
|
UTP Connection |
"Press-Fit" terminal blocks |
|
|
Power |
No power required |
|
|
Case |
ABS Plastic |
|
|
Dimension |
39mm*16mm*19mm with 14cm BNC connector |
|
|
Weight |
58g/pair |
|
