24 Ports Gigabit Ethernet Switch (SW24GS)

24 Ports Gigabit Ethernet Switch (SW24GS)

Main Features

◆ 24GE Rj45, 500Mhz CPU, 4.1M cache

◆ Support camera, wireless AP, and IP phone etc.

◆ Fluid Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure.

◆ Auto MDI/MDIX.

◆ Support port lightning protection.

◆ Store-and-forward.

◆ All ports support wire speed switch, jumbo frame transmission.

◆ Plug and play, self-adaption.

◆ Panel lights can monitor operative mode and malfunction analysis.

Model	SW2408SE
1000M Rj45	24
Exchange Mechanism	Store-and-forward
Property	500Mhz CPU, 4.1M cache
Bandwidth	52G
MAC	8K
Environmental	Working Temperature:0℃-40℃ Storage temperature :-40℃-70℃
Environmental	Working Humidity :10%-90% RH non-condensing Storage Humidity:5%-90% RH non-condensing
Power	AC 100-240V 50/60Hz
Standards Protocols	IEEE 802.3 IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3x
Speed	Ethernet 10Mbps half-duplex, 20Mbps full-duplex Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex Gigabit Ethernet 2000Mbps full-duplex
Network Media	10Base-T: Pair 2 Category 3(Cat3) and above UTP/STP(≤150m) 100Base-TX: Pair 2 Category 5(Cat5) and above UTP/STP(≤150m) 1000Base-T: Pair 4 Category 6(Cat6e) and above UTP/STP(≤150m)
Product specifications	Product Size:285mm220mm45mm(LWH) package Size:410mm280mm95mm(LWH) Weight:2kg
